Waveshare 7inch HDMI LCD (C), 1024×600, supports various systems


Quick Overview

7 inch Capacitive Touch Screen LCD, HDMI interface, supports various systems


  • 7 inch Capacitive Touch Screen LCD
  • HDMI interface, supports various systems
  • Features 1024×600 high resolution Capacitive touch control Supports Raspberry Pi Supports Banana Pi / Banana Pro, comes with Lubuntu, Raspbian images Supports BB Black, comes with Angstrom image For other mini-PCs, driver is required and should be developed by users Not only for mini-PCs, it can work as a computer monitor just like any other general HDMI screen HDMI interface for displaying, USB interface for touch control Backlight can be turned off to lower power consumption
  • For revisions under Rev2.1: For the Raspberry Pi, comes with Raspbian driver (works with your Raspbian directly), and Ubuntu image When work as a computer monitor, touch function is unavailable Rev2.1
  • New Features: Standard HID protocol, easy to be integrated into your system For the Raspberry Pi, supports Raspbian, Ubuntu, single touch, and driver free When work as a computer monitor, supports Windows 10/8.1/8/7, five-points touch, and driver free


  • to use the LCD with following mini-PCs, additional cables are required and should be purchased separately
  • Raspberry Pi Zero: HDMI cable, USB-type-A-receptacle-to-Micro-B-plug-cable
  • BB Black: HDMI cable
